Huidu HD-C16 HD-C16C Full Color controller card with Wifi solution

Name: Huidu HD-C16 HD-C16C Full Color controller card with Wifi solution
Brand: Shopping LED Screen controller Video processor power supply
SKU: HD-C16
Price: 70 USD
Availability: InStock

SKU: HD-C16

$70.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites

Description
Shipping Policy
Why Us

Huidu HD-C16C Led Screen Controller Features:

Control range. 122,880 pixels (384*320).

4GB memory, supports memory expansion via USB flash drive.

Supports HD video hardware decoding with 60Hz frame rate output.

Supports up to 8192 pixels wide and up to 512 pixels.

No need to set IP address, can be automatically identified by controller ID.

Unified management of multiple LED displays via Internet or LAN.

Equipped with Wi-Fi function, can be managed directly with cell phone APP.

Equipped with 3.5mm standard audio interface output.

Also supports adding 4G network module to connect to the Internet (optional).

Equipped with a 2-wire 50PIN HUB port for one receiving card.

Equipped with 1 set of relay modules to support remote direct power on/off.

Huidu HD-C16C Led Screen Controller Features:

Control Range: 120,000 pixels (384*320). 4GB memory, support expending memory by U-disk.

Support HD video hardware decoding, 60Hz frame rate output.

Support widest 8192 pixels, I lighest 512 pixels. No need set IP address, it could be identilied by controller ID automatically.

Unified management of more LED display through Internet or LAN.

Equipped with Wi-Fi function, Mobile APP management directly.

Equipped with 3.5mm standard audio interface output.

Meanwhile support to add 4G networking module connect to Internet (Optional).

Equipped with 10 lines HUB75E port, can be used for one receiving card.

Equipped with 1 group of relay module, support switch on/off power supply directly remotely.

Specifications Download

Huidu HD-C16 Specification V0.1

Huidu HD-C16C Specification V0.1
